FC-2 Features
54 SL500: Interface Reference Manual • July 2008 Revision: F • 96122
Class 3 Service Parameters, Port Login
TABLE 5-7 Class 3 Service Parameters, Port Login
Parameters Word Bits Value FC-Tape
Class validity 0 31 1 1
Service Options: 0 30–16
Intermix Mode 0 30 0 –
Stacked Connect Requests 0 29–28 00 –
Sequential Delivery 0 27 0 –
Dedicated Simplex 0 26 0 –
Camp-On 0 25 0 –
Buffered Class 1 0 24 0 –
Priority 0 23 0 –
Initiator Control: 015–0– –
Sequence Initiator X_ID reassignment 0 15–14 00 –
Initial Responder Process_Associator 0 13–12 00 00
Sequence Initiator ACK_0 capable 0 11 0 –
Sequence Initiator ACK_N Capable 0 10 0 –
ACK generation assistance 0 9 0 –
Initiator Data compression capable 0 8 0 0
Initiator Data compression history buffer size = 00b 0 7–6 00 –
Data Encryption Capable 0 5 0 0
Clock Synchronization Capable 0 4 0 P
Recipient Control: 1 31–16 – –
ACK_0 Capable 1 31 0 –
ACK_N Capable 1 30 0 –
X_ID Interlock 1 29 0 –
Error Policy Supported 1 28–27 0 01
Categories per sequence 1 25–24 00 00
Data compression capable 1 23 0 0
Data compression history buffer size 1 22–21 00 –
Data decryption capable 1 20 0 0
Clock synchronization capable 1 19 0 A
Reserved – fabric-specific 1 18–16 000 0
Receive data field size 1 15–0 0800h 256
Concurrent Sequences > 0 2 31–16 00FFh 1
N_Port End-to-end Credit 2 14–0 0000h –
Open Sequences per Exchange > 0 3 31–16 0001h 1
Class 6 Multicast RX_ID 3 15–0 0000h –
