8. V-BELT DRIVING SYSTEM
8-6
Remove starter drive pulley and volute spring
Caution
y If remove the volute spring from the l crank
cover then its has to be replaced.
Loosen the starter rope from the starter grip.
Installation
Install in reverse order of removal procedures
Caution
First before installing the drive pulley must
establish 2 1/2 of the pressures transferred to
pressure springs.
