17. ELECTRICAL SYSTEM
17-12
Meters
Remove
Remove the front fender.
Remove the radiator side 5 bolts.
Remove couplers of meter and main switch
couplers.
Remove 4 bolts from meter stay.
Remove 3 screws and speedometer lamps, them
disassemble steering cover and speedometer.
To this chapter contents
4 bolts
5 bolts
Main switch coupler
Meter set couplers
Speedometer cable3 screws
