2. MAINTENANCE INFORMATION
2-8
Check The Rear Gear box
Remove rear wheels and rear axle.
Loosen 3 bolts and remove rear axle gear box
under protector.
Loosen the 4 bolts of Rear Gear Box from the drive
shaft side.
Loosen 4 bolts from rear gear box by inner-left side
of the bottom of vehicle.
Then remove the rear gear box..
Use your hand to rotate and check the Rear Gear
Box for abnormal noise or cloggy rotation.
Caution
y Do not attempt to disassemble the Rear
Gear Box. Please exchange the whole
assembly if necessary.
3 bolts
4 bolts
4 bolts
Rear axle
side.
Drive shaft
side.
To Next Page
