5. ENGINE REMOVAL
5-4
Remove fuel pipe and by-starter .
Loosen 1 screw from throttle lever side cover them
remove the side cover.
Loosen throttle cable adjustment nut. remove the
throttle cable.
Release the clamp stripes and remove the carburetor .
Release the clamp strips of left crankcase cover
ducts, and then remove the ducts.
by-starter
clamps
Clamps
To this chapter contents
fuel pipe
Clamp
1 screw
