88 TimeSource 3100
Installation
097-72020-01 Issue 9: November 2003
SSSSSSSSSSS SSSS S SSSSS SSSS SSS S SSS S SSSSS S
3
27 If not using an Element Manager, skip to Step 29. If not using a separate port to send
autonomous messages to an Element Manager, skip to Step 28. Use the Edit Equipment
command to set the IP address and port address of the Element Manager. Port 5550
connects to this address when the TimeSource 3100 develops a TL1 autonomous
message, sends any messages, and closes the connection. An alternate Element Manager
may be set up in case port 5550 cannot make a connection to the primary Element
Manager.
ED-EQPT::TS3100:<ctag>:::IPEM1=a,IPEM1PORT=b[,IPEM2=a]
[,IPEM2PORT=b][,IPINACT=c];
IPEM1=a=Primary Element Manager's IP address in the form a.a.a.a (each a is an
independent value of 0 to 255)
IPEM1PORT=b=Primary Element Manager's Ethernet port address (b = 0 to 65535)
IPEM2=a=Alternate Element Manager's IP address in the form a.a.a.a (each a is an
independent value of 0 to 255)
IPEM2PORT=b=Alternate Element Manager's Ethernet port address (b = 0 to 65535)
IPINACT=c= Disconnects from the Element Manager if an autonomous message is not
developed during this number of 100-ms units of inactivity (0 to 10,000, where 0
deactivates the timer)
Procedure E. Power-Up (cont’d)
Step Procedure
To Next Page
