SYSTEMA EOLO RT rev. 09ENIT04052021
FEATURES
Description U.M.
BC/NBC
100
BC/NBC
120
BC/NBC
150
BC/NBC
200
BC/NBC
250
BC/NBC
300
Gas solenoid valve 822 Novamix/VK4415 VR 415 VR 420 VR 420 VR 425
Gas blower NRG 137 / FASCO GPM5.8H RG 175 RG 175 G1G 170 G1G 170
Flame controller BRAHMA SRM DFCM32C
Control electronics (motherboard) SCP674V130A1
Control electronics automatic - OPTIONAL (slave card, if
present) see paragraph 4.1.13 on page 44
SCP674V202
PA1: Fan with belt transmission - xed ow rate - available useful pressure 200 Pa
Fan model
ADH E0-
0355
ADH E0-
0400
ADH E0-
0450
ADH E0-
0500
ADH E0-
0560
ADH E0-
0630
Number of fans x motor rated power kW 1x3,00 1x4,00 1x5,50 1x7,50 1x7,50 1x11,00
Total nominal electric power kW 3,25 4,25 5,79 7,82 7,97 11,48
PA2: Fan with belt transmission - xed ow rate - available useful pressure 400 Pa
Fan model
ADH E0-
0355
ADH E0-
0400
ADH E0-
0450
ADH E0-
0500
ADH E0-
0560
ADH E0-
0630
Number of fans x motor rated power kW 1x4,00 1x5,50 1x7,50 1x11,00 1x11,00 1x11,00
Total nominal electric power kW 4,25 5,75 7,79 11,32 11,47 11,48
PA3: Fan with belt transmission - xed ow rate - available useful pressure 600 Pa
Fan model
ADH E0-
0355
ADH E0-
0400
ADH E0-
0450
ADH E0-
0500
ADH E0-
0560
ADH E0-
0630
Number of fans x motor rated power kW 1x5,50 1x7,50 1x11,00 1x11,00 1x15,00 1x15,00
Total nominal electric power kW 5,75 7,75 11,29 11,32 15,47 15,48
PF/AC Direct drive fan - xed ow rate - available useful pressure 400 Pa (for request)
Fan model R4D630… R4D630… R4D630… R4D630… R4D630… R4D630…
Number of fans x motor rated power kW 3,57x1 3,57x1 3,57x1 3,57x2 3,57x2 3,57x2
Total nominal electric power kW 3,82 3,82 3,86 7,46 7,61 7,62
PF1 (BC/NBC): Plug fan with variable ow rate - useful pressure available up to 200
Fan model
K3G500-
PA28-03
K3G500-
PA28-03
K3G500-
PA28-03
K3G500-
PA28-03
K3G500-
PA28-03
K3G500-
PA28-03
Number of fans x motor rated power kW 1x3,80 1x3,80 1x3,80 2x3,80 2x3,80 2x3,80
Total nominal electric power kW 4,05 4,05 4,09 7,92 8,07 8,08
PF2 (BC/NBC): Plug fan with variable ow rate - useful pressure available up to 400 Pa
Fan model
K3G 560-
PB31-03
K3G 560-
PB31-03
K3G 560-
PB31-03
K3G 560-
PB31-03
K3G 560-
PB31-03
K3G 560-
PB31-03
Number of fans x motor rated power kW 1x4,40 1x4,40 1x4,40 2x4,40 2x4,40 2x4,40
Total nominal electric power kW 4,65 4,65 4,69 9,12 9,27 9,28
PF3 (BC/NBC): Plug fan with variable ow rate - useful pressure available up to 600 Pa (800Pa for request)
Fan model
K3G-630
-PC08-03
K3G-630
-PC08-03
K3G-630
-PC08-03
K3G-630
-PC08-03
K3G-630
-PC08-03
K3G-630
-PC08-03
Number of fans x motor rated power kW 1x4,25 1x4,25 1x4,25 2x4,25 2x4,25 2x4,25
Total nominal electric power kW 4,50 4,50 4,54 8,82 8,97 8,98
Tab. 3.3 Principles of components for BC / NBC version devices (2 of 2)
Fan model may change depending on current product availability
