SYSTEMA EOLO RT rev. 09ENIT04052021
FEATURES
Description UM
BC/NBC
25
BC/NBC
35
BC/NBC
45
BC/NBC
55
BC/NBC
65
BC/NBC
85
Gas solenoid valve 848 Sigma 848 Sigma 848 Sigma 848 Sigma 848 Sigma
822 Novamix/
VK4415
Gas blower NRG 118 NRG 118 NRG 118 RG 148 RG 148
NRG 137
/ FASCO
GPM5.8H
Flame controller BRAHMA SRM DFCM32C
Control electronics (motherboard) SCP674V130A1
Control electronics automatic - OPTIONAL (slave card, if
present) see paragraph 4.1.13 on page 44
SCP674V202
PA1: Fan with belt transmission - xed ow rate - available useful pressure 200 Pa
Fan model
ADH E0-
0180
ADH E0-
0225
ADH E0-
0250
ADH E0-
0250
ADH E0-
0355
ADH E0-
0355
Number of fans x motor rated power kW 1x1,10 1x1,10 1x2,20 1x2,20 1x2,20 1x3,00
Total nominal electric power kW 1,19 1,19 2,29 2,42 2,42 3,25
PA2: Fan with belt transmission - xed ow rate - available useful pressure 400 Pa
Fan model
ADH E0-
0180
ADH E0-
0225
ADH E0-
0250
ADH E0-
0250
ADH E0-
0355
ADH E0-
0355
Number of fans x motor rated power kW 1x1,50 1x1,50 1x3,00 1x3,00 1x3,00 1x4,00
Total nominal electric power kW 1,59 1,59 3,09 3,22 3,22 4,25
PA3: Fan with belt transmission - xed ow rate - available useful pressure 600 Pa
Fan model
ADH E0-
0180
ADH E0-
0225
ADH E0-
0250
ADH E0-
0250
ADH E0-
0355
ADH E0-
0355
Number of fans x motor rated power kW 1x2,20 1x2,20 1x4,00 1x4,00 1x4,00 1x5,50
Total nominal electric power kW 2,29 2,29 4,09 4,22 4,22 5,75
PF/AC Direct drive fan - xed ow rate - available useful pressure 400 Pa (for request)
Fan model R4D450… R4D500… R4D560… R4D560… R4D560… R4D630…
Number of fans x motor rated power kW 1x0,71 1x1,52 1x1,95 1x1,95 1x1,95 1x3,57
Total nominal electric power kW 0,80 1,61 2,04 2,17 2,17 3,82
PF1 (BC/NBC): Plug fan with variable ow rate - useful pressure available up to 200
Fan model K3G 355-… K3G 355-…
K3G 400-
PA27-03
K3G 400-
PA27-03
K3G 400-
PA27-03
K3G500-
PA28-03
Number of fans x motor rated power kW 1x1,10 1x1,10 1x3,80 1x3,80 1x3,80 1x3,80
Total nominal electric power kW 1,19 1,19 3,89 4,02 4,02 4,05
PF2 (BC/NBC): Plug fan with variable ow rate - useful pressure available up to 400 Pa
Fan model
K3G 400-
PA27-03
K3G 400-
PA27-03
K3G 450-
PA31-03
K3G 450-
PA31-03
K3G 450-
PA31-03
K3G 560-
PB31-03
Number of fans x motor rated power kW 1x3,80 1x3,80 1x4,50 1x4,50 1x4,50 1x4,40
Total nominal electric power kW 3,89 3,89 4,59 4,72 4,72 4,65
PF3 (BC/NBC): Plug fan with variable ow rate - useful pressure available up to 600 Pa (800Pa for request)
Fan model
K3G 450-
PA31-03
K3G 450-
PA31-03
K3G500-
PA28-03
K3G500-
PA28-03
K3G500-
PA28-03
K3G-630
-PC08-03
Number of fans x motor rated power kW 1x4,50 1x4,50 1x3,80 1x3,80 1x3,80 1x4,25
Total nominal electric power kW 4,59 4,59 3,89 4,02 4,02 4,50
3.5 MAIN COMPONENTS OF THE APPLIANCE
Tab. 3.3 Principles of components for BC / NBC version devices (1 of 2)
Fan model may change depending on current product availability
