SYSTEMA EOLO RT rev. 09ENIT04052021
FEATURES
Tab. 3.11
Fig. 3.12 EC plug fan
Fig. 3.11 Fan section standard.
POS. DESCRIZIONE POS. DESCRIZIONE
1 Fan section 6 Three-phase electric motor
2 Anti-vibration cushions 7 Motor pulley
3 V-belt tension adjuster screw 8 V-belt
4 Motor slide guides 9 Fan pulley
5 Engine support plate with belt tensioner
3.12 STANDARD FAN SECTION
3.13 EC PLUG FAN SECTION
