FUNZIONAMENTO
5.6.2 List of operating parameters SCP674V202
Please note
See section 7.9 on page 67 for the procedure for changing parameters (parameter
menu).
Legend parameter type and password
☺ = USER parameters (password = any).
I = INSTALLER parameters. Before changing the value, read the instructions carefully (password = 95)
C = BUILDER parameters. These parameters are typically set by the manufacturer, the default values may be
di󰀨erent from the recommended ones. Changing them may cause the connected equipment to malfunction.
These parameters are only visible by entering the correct password.
ABBREVIA-
TION
PARAMETER TYPE RANGE UM DEFAULT
/ Control probe parameters
/A Probe average P3-P4. /A=0 → 100% P3 (*) C 0...100 °C 50
/C1 Calibration of probe P1 - temperature probe ☺ -12…12 °C 0,0
/C2 Calibration of probe P2 - external probe I -12…12 °C 0,0
/C3 Calibration of probe P3 - ventilation probe 1, incoming air I -12…12 °C 0,0
/C4 Calibration of probe P4 - ventilation probe 2, outlet air I -12…12 °C 0,0
/P2 Probe P2 conguration. no=absent; int=internal; C no… int - NO
/P4 Probe P4 presence. NO=NO; YES=YES C NO..YES - NO
/S AD input reading stability I 0…5 - 2
r Controller parameters
r0
Selects whether the controller operates with 1 or 2 set-points.
1=SP1C only. 2=SP1C+SP1E
C 1…2 - 1
rd Set-point differential ☺ 0,1…12 °C 0,5
rt Safety set-point / antifreeze function. 0=burner output off, antifreeze function off. ☺ 0,0…20 °C 6
rL Minimum temperature limit SP1C and SP1E I -40…rH °C 10
rH Maximum temperature limit SP1C I rL…99 °C 30
L Output parameters
L0 Output activation delay at PWON C 15…250 sec 15
L2 Reset pulse duration C 1…30 Sec 7
LbP Proportional band I 1…12 °C 3
LP
Burner power control mode:
0 = burner modulated by room temperature;
1 = burner modulated by air ow temperature
C 0...1 0
LrA
Automatic correction parameter LrH. Represents the value of the maximum burner output if
outside temperature Et ≥ Ln8.
I 30…100 % 50
Ln6
Minimum outside temperature value for calculation of automatic correction algorithm for
parameter LrH, 'LrA'.
I -20…Ln8 °C -20
Ln8
Maximum outside temperature value for calculation of automatic correction algorithm for
parameter LrH, 'LrA'.
I Ln6…15 °C 15
Tab 5.20 Operating parameters SCP674V202 (1 of 2)
