FEATURES
Tab. 3.6 Overall dimensions of the basic version
[mm]
EOLO BC/BL
25/35 RT
EOLO BC/BL
45/55/65 RT
EOLO BC/BL
85/100/120 RT
EOLO BC/BL
150 RT
EOLO BC/BL
200 RT
EOLO BC/BL
250 RT
EOLO BC/BL
300 RT
A 1205 1508 1909 2008 2260 2510 2260
B 788 1035 1197 1560 1560 1560 2210
C 350 410 530 695 695 690 600
D 700 900 1200 1000 1200 1400 1500
E 150 190 170 305 355 410 150
F 1200 1500 1900 2000 2250 2500 2250
G 200 271 149 300 300 300 325
H 400 500 900 1000 1000 1000 1500
I 188 264 148 260 260 260 285
J 1580 1822 2200 2500 2500 2500 3600
K 1400 1643 2092 2392 2392 2392 3492
L 1504 1745 2193 2500 2500 2500 3600
M 150 190 250 400 425 450 125
N 700 900 1400 1200 1400 1600 2000
O 350 410 250 400 425 450 125
P 200 269 151 300 300 230 325
Q 400 500 900 1000 1000 1000 1500
R 188 266 146 260 260 330 285
ØS 100 100 130 200 200 200 300
T 98 100 150 133 157 182 112
U 450 600 700 800 900 1000 900
V 104 100 200 85 136 136 226
W 450 600 700 800 900 1000 900
X 98 100 150 157 157 182 112
Y 151 172 149 230 230 230 325
Z 500 700 900 1000 1000 1000 1500
AA 137 163 148 330 330 330 285
