SYSTEMA EOLO RT rev. 09ENIT04052021
FEATURES
Tab. 3.7
Fig. 3.7 Main components - delivery side view
POS. DESCRIPTION POS. DESCRIPTION
1 Smoke exhaust duct 9.1 Fresh air intake vent (optional)
2 Electrical cabinet
9.2 Fresh air intake vent (optional - double intake version)
3 Safety thermostat (Ts) with manual reset
4 Access door to the burner housing compartment 10 Internal air intake (optional - double intake version)
5 Burner 11 Air delivery
6 Condensate drain (BC version only) 12 Exchanger
7 Gas connection
13
Main disconnector and control panel connection terminal
block
8 Access door to the fan housing compartment
SIDE VIEW - SUPLY FLANGED PANEL
