➤ US Postnet Barcode Postnet is a special US-American type of barcode. It is printed in charac-
ter size. Numeric values from 0 to 9 are printable.
After activating this barcode type, numeric characters from 0 (hex. 30) to
9 (hex. 39) are interpreted as barcode figures. All other characters termi-
nate the Barcode mode. Exception: the TAB - function (hex. 09) is
allowed within Barcode mode. The Postnet sequence is accessible in
every emulation. The printer can print barcode in NLQ (180 dpi) and LQ
(360 dpi). If draft print quality (DPQ) is selected the printout is performed
in NLQ.
The character (e.g. CR = carriage return, hex. 0D), which terminates
the barcode is not printed or carried out.
US Postnet Barcode does not require a barcode bracket.
Example:
ASCII ESC[1 SP p 12345 CR
Hex. 1B 5B 31 20 70 31 32 33 34 35 0D
The numbers 1 to 5 are printed as Postnet stripes.
