Transmission length: max. 15 m
BACK
QUIT
?
PRINT
Reference manual Interfaces
160
Connector assignment
Connector no.
Direction
Printer– PC
Signal
3
→
TxD
4
→
DTR
2
←
RxD
6
←
DSR
7
→
RTS
8
←
CTS
5
Signal Ground
SG
Schirm
Frame Ground
FG
