TallyGenicom MATRIX PRINTER 2150 - Paper feed; Printhead gap; Paper transport

Dimensions Narrow printer Wide printer
Width
Height
Depth
424 mm 600 mm
300 mm 300 mm
399 mm 399 mm
Weight
Narrow printer Wide printer
10.5 kg 13.2 kg
Paper feed
Feed speed3,8 ips
Feed first line (6 lpi)48 ms
View position3,8 ips
Reverse motion Up to max. form length (22 inch)
max. 1 inch for automatic single sheet feeder
Printhead gap
Standard Automatic gap adjustment
Paper transport
Standard – Tractor with parking position
– Manual single sheet feeder, front insertion
(friction rollers)
Optional – Automatic single sheet feeder front and rear
– Tractor 2 (front) and 3 (rear)
BACK
QUIT
?
PRINT
Reference manual Specification
173
