5-5
Brake Linkage/ Accelerator Pedal
ITEM# PART# DESCRIPTION QTY
1 88-140-14 1/2” NC X 1-1/2” Hex Head Cap Screw 1
2 98-200-00 Brake Pedal Pad, Rubber 1
3 88-089-81 1/2” NC Locknut 2
4 01-534-67 Brake Arm Weldment 1
5 88-140-14 1/2” NC X 1-1/2” Hex Head Cap Screw 1
6 96-772-00 3/8” X 1” Clevis Pin 3
7 85-060-00 Return Spring 1
8 96-813-00 28-1/4” to 31-1/4” Brake Cable Assy 1
9 88-517-11 3/32” X 1” Cotter Pin 7
10 62-033-00 Accelerator Module 1
11 98-254-10 Accelerator Pedal 1
12 50-432-00 Brake Pedal Connecting Link 1
13 96-771-00 3/8” X 3/4” Clevis Pin 1
14 51-508-00 Brake Pedal, w/P.Brake Locks 1
