Taylor-Dunn MX6-00 - Lubrication Schedule

3-5
Lubrication
# Description Locations Lubricant
1 Front Wheel Bearing 1 High Temp Wheel Bearing Grease
2 Front Fork Pivots 2 General Purpose Grease
3 Steering Collars 1 General Purpose Grease
4 Brake Shaft Collars 2 General Purpose Grease
5 Rear Axle Differential 1 SS-536, SS 5-46, MX-600, SAE 30 Motor Oil
SS5-34, SAE 140 API GL-5 Gear Oil
6 King Pin (SS5-46) 2 General Purpose Grease
1
2
3
4
5
1
6
7
SS5-46 Front Axle
