Taylor-Dunn MX6-00 - Front Fork and Steering Systems

3-20
SECTION 3
Front Fork and Steering
In this section, we will cover how to service and repair the front fork, axle, and
steering assemblies. Included in the steering will be the tiller steering system and
the geared steering system.
The standard steering assembly for the SS5-34, SS5-36, and MX-600 is the Tiller.
Since the Geared option is widely used in these vehicles as well, we included it in
this section. Geared steering is standard on the SS5-46.
SS5-34
Geared Steering
SS5-36/5-46, MX-
600 Geared Steering
SS5-34, SS5-36
and MX-600
Tiller Steering
