Front Fork
Here, we will cover the Front Fork only. The following procedures will cover the
disassembly and repair of the front fork and the axle. ,
NOTE: There are two types of front axles used within the
serial numbers covered by this manual. The basic instructions
for removing, servicing and installing are the same.
LOWER
LOCATOR
TOP
LOCATOR
OIL
SEAL
AXLE
BEARING RACE
ROLLER BEARING
SPACER
AXLE NUT
WASHER
SPRING
Front Axle
Bumper Spacer
3/4" NC Washer
3/4" NC Locknut
Tire/Wheel Assembly
Front Fork
Spring
Axle assembly using two axle nuts
Axle assembly using one axle nut
To Next Page
