3-14
SECTION 3
Inspecting and Replacing the Park Brake Lock(All
Models)
Foot Brake Assembly: Shown is the brake pedal, and how it connects to the
brake cables on the SS5-36, SS5-46 and MX-600.
Locknut
Mounting Bolt
Clevis
Jam Nut
Adjusting Bolt
Points
Park Brake Lock
Forward
