5-7
Brake Linkage (SS5-36, sS5-46 and MX-600)
ITEM# PART# DESCRIPTION QTY
1 88-140-13 1/2” X 1/4” NC Bolt 1
2 02-536-09 Pedal Lock 1
3 98-200-00 Pedal Pad 1
4 88-149-81 1/2” NC Locknut 1
5 88-527-11 1/8” X 1” Cotter Pin 1
6 96-762-00 Clevis 1
7 88-119-81 3/8” NF Jam nut 1
8 88-111-20 3/8” X 3” NF Bolt 1
9 96-826-12 Park Brake Cable Assy 1
10 02-536-06 Brake Equalizer 1
11 96-772-00 3/8” X 1” Clevis Pin 1
12 62-033-00 Accelerator Module 1
13 98-254-10 Accelerator Pedal 1
14 88-847-08 E-clip 2
15 85-125-00 Spring 2
16 96-754-00 Clevis 2
17 88-517-11 Cotter pin 2
18 96-773-00 Clevis pin 2
To Next Page
