5-11
Front Axle, Wheel and Suspension (SS5-46)
ITEM# PART# DESCRIPTION QTY
1 92-104-00 Bearing cap 2
2 88-527-14 Cotter pin 2
3 88-239-85 Castle nut 2
4 88-228-61 3/4 SAE Flat washer 2
5 80-017-00 Bearing 1
6 80-103-00 Race 1
7 12-124-15 Hub 2
8 80-103-00 Race 1
9 80-017-00 Bearing 1
10 45-338-00 Seal 2
11 00-546-06 Left steering yoke 1
00-546-07 Right steering yoke 1
12 88-109-81 3/8NC Lock nut 4
13 97-202-50 3/8NF nut, left thread 2
88-199-80 3/8NF Hex nut 2
14 86-519-11 Rod end, left thread 2
86-519-10 Rod end, right thread 2
15 88-108-15 3/8 x 1-3/4 Hex bolt 4
16 88-106-61 3/8 SAE Flat washer 4
17 16-506-00 Upper spacer 4
18 16-506-00 Lower spacer 4
19 88-108-61 3/8 SAE Flat washer 4
20 01-546-16 Tie rod 2
21 32-200-00 Bushing 2
22 87-073-00 Grease fitting 2
23 21-020-15 King pin 2
24 32-240-55 King pin bushings (inside axle) 4
97-180-55 Thrust washer 4
25 88-189-81 5/8NC Lock nut 2
26 00-546-02 Steering arm 1
27 87-071-00 Grease fitting 1
