Taylor-Dunn MX6-00 - Page 145

5-13
Tiller Steering
ITEM# PART# DESCRIPTION QTY
1 19-101-20 Steering Tiller 1
2 88-140-14 1/2” X 1-1/2” NC Bolt 1
3 97-230-00 1-1/4” NF X 9/16” Locknut 1
4 16-409-00 Spacer 1
5 80-102-00 Bearing Race 2
6 14-079-20 Front Fork with Springs 1
7 85-140-10 Spring 2
8 97-100-00 Woodruff Key 1
9 80-011-00 1-1/4” Tapered Roller Bearing 2
10 45-307-00 Oil Seal, 1-1/2”ID 2
11 88-149-81 1/2” Locknut 1
Not Shown 72-005-00 4” Head Light 1
