Taylor-Dunn MX6-00 - Page 147

5-15
Geared Steering (SS5-34)
ITEM# PART# DESCRIPTION QTY
1 95-915-20 Cap, Black Plastic 1
2 88-199-82 5/8” Jam Nut 1
3 19-007-20 Steering Wheel 1
4 18-309-00 Gear Box Only,(With Bolts, Bushings,
and Zerk Fittings.) 1
5 88-068-25 1/4” X 4-1/2”NC HEX Hd Cap Screw 6
6 88-068-62 1/4” Lockwasher 6
7 32-203-00 3/4” ID X 7/8” OD X 1/2” Long Bronze
Bushing 1
8 97-100-00 3/16” Woodruff Key 1
9 20-031-00 Steering Shaft with Gear 1
10 31-253-00 36-Tooth, Spur Gear, .750 bore 1
11 80-706-00 3/4”OD O-Ring 1
12 31-255-00 7-Tooth Stem Pinion 1
13 45-003-00 4” X 4-1/2”OD Gasket 1
14 45-004-00 4” X 6” OD Gasket 2
15 32-207-00 3/8”ID X 5/8”OD X 1/2” Long
Bronze Bushing 1
16 88-088-62 5/16” Lockwasher 3
17 88-088-11 5/16” X 1” HEX Hd Cap Screw 3
18 31-254-00 36-Tooth Spur Gear, .875 bore 1
19 87-074-00 1/4”-28NF Zerk Fitting 1
20 87-071-00 3/16” Zerk Fitting 1
21 80-400-10 3/4”ID Ball Bearing 2
22 16-405-00 3/4”ID X 1-1/4”OD Spacer 1
Not Shown 72-005-00 4” Headlight 1
Not Shown 72-505-05 Headlight Mount 1
