5-25
Motor GE spec# 5BC58JBS6129A
ITEM # PART # DESCRIPTION QTY
70-049-05 Complete motor assembly (does not include #11)
1 70-201-15 Field coils (mounted in motor housing) 1
2 70-210-51 Inulator 2
3 85-412-00 Brush spring 4
4 70-172-15 Brush holder (includes #3) 1
5 70-104-15 Motor brush (2) 2
6 70-210-51 Insulator 2
7 32-508-15 Bearing retainer 1
8 80-209-00 Bearing 1
9 88-089-91 5/16NC Jam nut 4
10 88-088-61 5/16 SAE Flat washer 4
11 - - -
12 70-049-06 Bushing spacer 1
