5-27
SS5-34 Rear Axle
ITEM# PART# DESCRIPTION QTY
1 85-140-00 2-7/16" X 6-1/4" Spring 1
2 96-240-00 1/2" X 4” Bolt 2
3 98-601-00 Rubber Grommet, 1/2" ID 4
4 88-149-81 1/2"NC Locknut 2
5 45-045-00 Rear Axle Bearing Gasket 2
6 45-301-00 Oil Seal 2
7 32-515-00 Bearing Retainer Ring 2
8 80-503-00 Bearing for Rear Axle 2
9 32-514-00 Rear Axle Retaining Plate 2
10 41-166-11 Right Side Axle w/ Bearing and
Retainer Plate 1
41-165-11 Left Side Axle w/ Bearing and
Retainer Plate 1
11 88-180-18 5/8"NC X 2-1/2" Hex Head Bolt 2
12 86-602-00 Shock Absorber 1
13 41-296-00 Housing 1
To Next Page
