5-31
3rd Member and Axle Assembly
ITEM# PART# DESCRIPTION QTY
1 41-709-00 3rd member Housing
(1.628 ID Carrier Bearing) 1
41-710-00 3rd member Housing
(1.784 ID Carrier Bearing) 1
2 88-119-80 3/8" NF Nut 14
3 41-712-00 Differential Assembly
(1.628 ID Carrier Bearing) 1
41-713-00 Differential Assembly
(1.784 ID Carrier Bearing) 1
4 80-127-00 Carrier Bearing Race,
(For 1.628 ID Carrier Bearing) 2
80-128-00 Carrier Bearing Race,
(For 1.784 ID Carrier Bearing) 2
5 80-511-00 Carrier Bearing
(1.628 ID Carrier Bearing) 2
80-512-00 Carrier Bearing
(1.784 ID Carrier Bearing) 2
6 31-235-00 Ring and Pinion Gear Set (2.69-2.75) 1
7 41-997-00 Oil Plug 3
8 41-296-00 Rear End Housing 1
9 80-554-00 Pinion Bearing 2
10 41-711-00 Pinion Housing Shim 1
11 80-702-00 O-Ring 1
12 44-340-90 Pinion Housing Shim 1
13 16-419-00 .002 Shim (Add Shims As Needed) *
16-420-00 .010 Shim (Add Shims As Needed) *
16-411-00 .005 Shim (Add Shims As Needed) *
14 16-415-00 Spacer 1
15 80-125-00 Pinion Bearing Race 2
16 41-707-00 Differential Bearing Adjuster Nut
(For 80-511-00) 2
41-707-50 Differential Bearing Adjuster Nut
(For 80-512-00) 2
17 88-080-04 5/16" X 3/8” NC Hex Bolt 2
18 88-140-16 1/2" X 2" Hex Bolt 2
19 96-243-00 7/16" X 7/8" Hex Bolt (Locking Head) 10
Not Shown 45-339-00 Oil Seal, Pinion Shaft 1
41-701-00 Roll Pin, Spider Gear Shaft 1
