5-37
MX-600 Deck and Vise Assy
ITEM# PART# DESCRIPTION QTY
1 90-408-20 30" X 27-1/2" Deckboard 1
2 88-065-13 1/4” NC X 1-1/4" Truss Head Screw 3
3 88-068-61 1/4" SAE Washer 5
4 97-840-01 4-1/2" Jaw Width Vise 1
5 00-380-01 Vise Mount Plate 1
6 88-100-15 3/8"NC X 1-3/4" Hex Head Bolt 3
7 88-108-62 3/8" Lockwasher 3
8 88-069-81 1/4" Locknut 2
9 97-211-20 1/4" NC Retainer Nut 1
Not Shown 91-340-21 Tool Box Lock 1
91-340-26 Keys for Toolbox Locks 1
00-300-08 Steel Deck Cover 1
