5-43
Mechanical Brake Band Assy (SS5-34)
ITEM# PART# DESCRIPTION QTY
1 88-100-11 3/8" NC X 1-3/4” hex Head Cap Screw 1
2 96-771-00 3/8" X 3/4" Clevis Pin 2
3 97-250-00 3/4"-20 Extra Fine Pinion Nut 1
4 85-060-20 5/8"" OD X 2-1/2"" Compression Spring 1
5 41-660-60 Brake Half Band 1
6 96-245-10 1/2" NC X 5" hex Head Cap Screw 1
7 85-270-00 1-1/4" OD X 4-3/8" Extension Spring 1
8 50-661-00 Brake Lever Bar 1
9 41-532-00 Brake Drum 1
10 88-517-11 3/32" X 1" Cotter Pin 2
11 88-089-81 5/16"NC Locknut 4
12 50-662-00 Brake Lever 1
13 88-080-11 5/16" NC X 1" Hex Head Cap Screw 2
14 88-159-82 1/2"NF Jam Nut 1
15 88-159-84 1/2"-20 NF Locknut 1
16 41-380-10 Brake Mounting Bracket 1
17 88-089-81 5/16" NC Locknut 2
18 45-339-00 Pinion Seal 1
