Taylor-Dunn MX6-00 - Page 179

5-47
PMC Control Panel
ITEM# PART# DESCRIPTION QTY
1 88-838-06 #14 X 1/2" Pan Head Screw 4
2 62-204-00 PMC Controller 1
3 72-501-43 Forward/Reverse Solenoid 2
4 61-838-41 5/8" X 1-1/2" Bus Bar 2
5 88-088-62 5/16" Lockwasher 10
6 88-099-91 5/16" Nut 10
7 88-048-62 #10 Lockwasher 6
8 88-049-80 10-32 Nut 6
9 61-838-42 3/8" X 2-5/8" Bus Bar 2
10 72-501-42 ISO Solenoid 1
11 79-840-00 10-Amp Circuit Breaker 2
12 79-844-00 135-Amp Auto Reset Circuit Breaker 1
13 88-080-11 5/16" X 1" Hex Head Cap Screw 4
14 01-534-89 Control Panel Mount
(SS5-34 & SS5-36) 1
00-300-03 Control Panel Mount (MX-600) 1
15 73-004-20 12V Horn 1
16 88-088-62 5/16" Lockwasher 4
17 88-089-80 5/16" Hex Nut 4
18 88-818-06 #8 X 1/2" Pan Head Screw 7
Harnesses and Panel Assy
ITEM# PART# DESCRIPTION QTY
Not 75-148-43 Control Panel Harness (MX-600) 1
Shown 75-148-25 Control Panel Harness
(SS5-34 & SS5-36) 1
75-149-25 Power Harness (All) 1
62-015-07 Control Panel Assy(MX-600) 1
62-015-00 Control Pnl Assy (SS5-34 & SS5-36) 1
