GEN. INSTR.
M5GENIN
Rev 1.0 Page 6
19. MODULE SLOTS
This is where the M5000 module cards are installed.
With four module slots the M5000 frame can house
for example 4 full stereo reverbs modules with
digital I/Os.
20. OPTION
Future OPTION such as SCSI, PCMCIA and other
future expansions may be configured to this port.
21. GROUNDLIFT
In position OFF : Direct connection from internal
ground to chassis. In position ON : Internal ground
connection to chassis trough a capacitor. Also called
'flying chassis'.
22. AC CONNECTOR
Connector for AC power cord. 3 prong IEC type.
The center post is chassis ground. Input voltage :
100-240 Vac, 50-60 Hz.
23. SMPTE INPUT
Enables the M5000 to make program changes and
other pre-programmed functions as it is
synchronized to timecode. Refer to the “MIDI &
SMPTE” section for more information.
24. MIDI CONNECTORS
MIDI data can be read and generated from these
connectors. MIDI THRU sends a duplicate copy of
the data received at MIDI IN.
25. REMOTE
Connects to the ATAC remote controller. The port
communicates with the remote through bi-
directional serial data transmission.
26. PEDAL CONNECTOR
Used for a simple external switch. The function of
the switch will be programmable.
