3-24
Fig. 3.80
Fig. 3.79
Fig. 3.78
■DISASSEMBLING TRANSMISSION
① Remove the forward/reverse clutch pack (1)
and 2nd clutch pack (2) from the transmission
case.
② Remove the counter gear (1) from the
transmission case.
③ Remove the suction pipe (1) from the
transmission case. (for 43E-25 only)
Note: The suction pipe (1) is not used with the
44E-25.
To Next Page
