TCM FD35C9 - Page 156

3-42
Fig. 3.142
4) Remove the shims (1) and spacer (2) from the
drive pinion.
Note: Record the type and number of shims.
5) Remove the outside bearing cup (1) and oil
seal (2) from the bearing cage.
6) Remove the bearing cup (1) from inside the
bearing cage.
Fig. 3.143
Press
JIG
Fig. 3.144
Press
JIG
