3-43
Fig. 3.145
■REASSEMBLING DIFFERENTIAL
① Reassembling drive pinion
1) Install the oil seal (2) on the bearing cage (1).
Note: Pay attention to the direction of the oil seal
when installing it.
2) Install the inside and outside bearing cups (1)
on the bearing cage.
3) Install the inside bearing cone (1) on the drive
pinion.
Press
JIG
Fig. 3.147
Fig. 3.146
Press
