2-7
Fig. 2.22
Fig. 2.23
Fig. 2.24
④ Connect the battery cable (3) to the battery 1’s
negative (-) terminal (1) and the battery 2’s
positive (+) terminal (2).
⑤ Connect the positive (+) battery cable (2) to
the battery 1’s positive (+) terminal (1).
Make sure to connect the battery cable
to the positive (+) terminal of the battery
rst.
⑥ Connect the negative (-) battery cable (2) to
the battery 2’s negative (-) terminal (1).
