2. General
2006-03 Instructions for Use for sunrise Absorbance Reader No. 30008746 Rev. No. 1.4 2-11
2.3.7 Barcode Laser Scanner
WARNING
LASER RADIATION – DO NOT STARE INTO THE BEAM!
CLASS II / 2 LASER PRODUCT.
The Class II / 2 Laser Scanner corresponds to the following norms:
• DIN EN 60825-1 : 2001
• CDRH 21 CFR 1040.10
PARAMETERS CHARACTERISTICS
Classification Class II / 2 Laser Product
Input power 5 V DC +/- 10%
Emission duration > 0.25 s
Scan rate 42 +/- 3 Scans / second (bi-directional)
Laser power < 1 mW
Definition of depth Max. 40 cm
Resolution 0.15 mm
Min. print contrast 25% at 675 nm
Ambient light Sun light: 40000 Lux
Halogen light: 1500 Lux
2.3.8 Microplates
Only 96-well format microplates (v-shaped, flat and round including strip-wells)
with transparent bottom can be used with the
sunrise Absorbance Reader.
PARAMETERS CHARACTERISTICS
Max. overall plate height 14.35 mm +/- 0.76 mm
(0.5650 inches +/- 0.0299 inches)
Diameter of wells 7.0 mm (0.276 inches)
Pitch size (center to center) 9.0 mm (0.3543 inches)
Bottom shape V-shaped, Flat and Round bottom
The barcode sticker has to be positioned on the right hand side of the plate,
7 mm from the front-right edge. The barcode may be up to 48 mm long.
2.3.9 Barcode Labels
The sunrise barcode scanner supports the following barcode types:
• Codabar
• Code 128
• Code 39
• Interleaved 2 of 5
