2. General
TECAN
2-12 Instructions for Use for sunrise Absorbance Reader No. 30008746 Rev. No. 1.4 2006-03
Barcode labels must fulfill the following norms:
• ISO/IEC 15416 Automatic identification and data capture techniques
• Bar code print quality test specifications
• Linear symbols (e.g. EN 1635).
• ANSI X3.182-1990 (R1995): Guideline for Bar Code Print Quality
Note
The barcode must have the quality Class A, B or C / ANSI/CEN/ISO
standard. Dirty, folded, wet or damaged barcode labels must not be
used. The adhesive labels must be flat and not peeling off at the edges.
We recommend to guarantee the quality of the barcode labels by means of local
SOP.
The barcode has to be accurately aligned horizontally and positioned on the right
hand side of the plate, 7 mm from the front-right edge. Position the barcode as
near as possible to the bottom.
7
6
55
1
PARAMETERS CHARACTERISTICS
Length max 48 mm (3.5 inch)
Bars height min 6 mm (0.24 inch)
Quiet zone min 5 mm (0.2 inch)
Resolution min 0.15 mm (5 mil) module width
Length max 29 digits
2.3.10 USB Stick
Please Note
Use always the currently Tecan released and Tecan approved USB
sticks! Otherwise data leakage may be possible.
PARAMETERS CHARACTERISTICS
Storage
>= 32 MB
Data retention
min. 2 years
Erase cycles
100,000 times
Do not expose the USB stick to extreme temperatures, fire, water, moisture, dust,
smoke, electrical power and mechanical forces.
