6. Maintenance & Cleaning
TECAN
6-6 Instructions for Use for sunrise Absorbance Reader No. 30008746 Rev. No. 1.4 2006-03
6.3.3 6 Filter Carriages
The filters of the 6 Filter carriages can be replaced using the following procedure:
1. Remove the filter carriage from the instrument.
2. Place the filter carriage on a clean flat surface, so that the Phillips head
screws are visible.
3. Remove the two screws and then remove the retaining bar that holds the
retaining pins.
4. Remove the filters. Be careful not to scratch the filters or soil them with
fingerprints or dust.
5. Insert the new filters and replace the retaining bar. Replace and tighten the
screws while pressing the retaining bar to the filters.
1 2 3 4 5 6
Filter positions
