2. General
TECAN
2-14 Instructions for Use for sunrise Absorbance Reader No. 30008746 Rev. No. 1.4 2006-03
2.4.1 Back Panel Connections
The illustration below shows the connections located in the back panel of the
instrument.
All connected devices must be approved and listed as per EN 60950, UL 1950 or
CSA C22.2 No. 950 for Data Processing Devices.
Barcode Laser Scanner Labels
Label reproductions on the instrument housing and interior:
Note
If any labels become damaged or removed, contact you local Tecan
representative for replacement labels.
Instrument main fuses
ON / OFF switch
Main socket
Printer interface (serial port)
(only available with touchscreen option)
Serial RS232 interface
Fuse values
Barcode laser scanner labels
(only available with barcode option)
