6. Maintenance & Cleaning
TECAN
6-2 Instructions for Use for sunrise Absorbance Reader No. 30008746 Rev. No. 1.4 2006-03
6.2 Lamp Replacement
Note
The instrument specifications can only be guaranteed if genuine Tecan
parts are used.
The following steps must be followed to replace the lamp:
Before replacing the lamp let the instrument cool down for at least thirty minutes.
1. Switch off the instrument and disconnect it from the main supply.
2. Remove the lamp compartment cover by gently pulling it from the underside.
3. Push the locating spring bar, on top of the lamp, to the left.
4. Carefully remove the lamp from the lamp holder.
WARNING
TO PREVENT BURNS, ENSURE THAT THE LAMP IS COLD.
5. Disconnect the lamp power cables from the lamp power connector.
6. Replace the old lamp.
7. Reconnect the lamp power connector.
8. Replace the lamp into the lamp holder.
Lamp
compartment
