6. Maintenance & Cleaning
2006-03 Instructions for Use for sunrise Absorbance Reader No. 30008746 Rev. No. 1.4 6-3
Please note that the lamp is held in place by three lugs, between which the lamp
is to be inserted.
Insert the lamp so that the cables are at the bottom.
Locating lugs
Lamp
Connecting plug
Spring bar
9. Lock the lamp into place using the spring bar.
10. Before closing the cover plate, ensure that the lamp is properly seated in the
three lugs.
11. Close the lamp compartment cover.
Caution
Do not touch the reflective surface and the bulb. Any fingerprints on
these surfaces must be removed with acetone or methylated spirits.
