4-12
Three selectable options are available for the display type. These are Resistance, Comparator, and %
Comparator.
Selecting either of the Comparator Display Modes will enable the Comparator LED’s on the front Panel
and their respective outputs on the rear panel.
MENU/CLEAR DISPLAY
Compare
% Compare
Resistance
ABSOLUTE COMPARATOR LIMITS
Comparator limits are entered into the 1750 in counts. Because the 1750 is a 4½ digit meter, the
maximum entered value would be 22999 counts. The lowest possible entry would be 00000. For the
high limit, any value less than the high limit value may be entered for the low limit and any limit lower
than the high limit may be entered as the lower limit.
MENU/CLEAR COMPARATOR
High 00000-22999
Low 00000-22999
