5-5
PROGRAMMING AND INTERFACING
CONNECTOR J8
Connector, J8 is used to provide contact outputs for the comparators, bins and other control outputs.
A standard DB-15 connector is required. The pin designations are illustrated below:
Figure 5.3: J8 Connections
8
15
1
9
CONNECTOR J8
Rear Panel View
15
14
13
12
11
HIGH
LOW
GO
10
9
8
7
6
5
4
3
2
D
COMPARATOR HIGH
TTL OPEN
COLLECTOR OUTPUT
1
COMPARATOR LOW
TTL OPEN
COLLECTOR OUTPUT
COMPARATOR GO
TTL OPEN
COLLECTOR OUTPUT
