4-15
PIN FUNCTION
Enter the PIN # to either enable or disable the PIN lockout function. Refer to the section on PIN function
located in this Section.
MENU/CLEAR
PIN Function
(unmarked key)
Enter PIN (3 digits)
CALIBRATION
The Pin function must be disabled in order to access this menu. In addition, an internal calibration
jumper must be in place to enable the calibration of this instrument. See section 6, on calibration for
an in depth description of calibration functions procedures.
MENU/CLEAR
[0]
ARE YOU SURE?
SEE CHAPTER
VI FOR
DETAILED
CALIBRATION
INSTRUCTIONS
AUTO CORRECT
The 1750 microohmmeter has an auto-correction feature that allows internal compensation of the
instrument for temperature changes in the operating environment. In earlier firmware revisions, the
auto correction feature was user-selectable. Currently, all 1750 units have this feature enabled and
the user cannot modify the feature.
This feature does NOT compensate for changes in resistance of the DUT due to ambient temperature
changes.
