4-13
% COMPARATOR LIMITS
For the % comparator, there are three programmable parameters; Upper % Limit, Lower % Limit, and
the Nominal Value. Values 00.00 through 99.99% may be entered for the upper and lower %
comparator limits. The nominal value is entered from 00000 – 22999, in counts.
MENU/CLEAR
% COMPARATOR
Nominal 00000-22999
Low 00.00-99.99%
High 00.00-99.99%
COMMUNICATION INTERFACE
GPIB, RS232 or RS422 communication is selected from this menu option. When the GPIB
communication mode is selected (by pressing the [ENTER] key once), an additional screen will appear
to allow a new GPIB address to be entered. Enter a new GPIB address by typing a number from 01 to
30 and pressing [ENTER]. The existing address may be retained by simply pressing [ENTER].
There are no user-defined settings available for the RS232 or RS422 communication modes.
RS232
GPIB
(IEEE-488.2)
RS422
MENU/CLEAR
INTERFACE
GPIB
ADDRESS
