5-10
PROGRAMMING AND INTERFACING
Description
Command
Action
Save Setup
Sn
Saves Current Setup to a specified location, where n=1-9
Set Trigger Type
T0
Fast Continuous on Talk or Front Panel Operation
T1
Fast One Shot on Talk or Front Panel Operation
T2
Delay Continuous on Talk or Front Panel Operation
[Default]
T3
Delay One Shot on Talk or Front Panel Operation
T4
Fast Continuous on GET
T5
Fast One Shot on GET
T6
Delay Continuous on GET
T7
Delay One Shot on GET
Status
U0
Send machine State
U1
Send Error Status
U2
Send Firmware Revision Level
U3
Send High Comparator Limit Value
U4
Send Low Comparator Limit Value
U5
Send Nominal Value
U6
Send High % Comparator Value
U7
Send Low % Comparator Value
Execute
X
Force Execution of preceding Command
Message Terminator
Y0
Append <CR><LF> as terminators
Y1
Append <LF><CR> as terminators
Y2
Append <CR> as terminators
Y3
Append <LF> as terminators
Table 5.3: RS232 Interface Command Summary
