PROGRAMMING AND INTERFACING
Description
Command
Action
Range
R0
Auto Range
R1
2 mΩ range @ 1 Amp Test Current
R2
20 mΩ range @ 1 Amp Test Current
R3
20 mΩ range @ 100 mA Test Current
R4
200 mΩ range @ 1 Amp Test Current
R5
200 mΩ range @ 100 mA Test Current
R6
2 Ω range @ 100 mA Test Current
R7
2 Ω range @ 10 mA Test Current
R8
20 Ω range @ 10 mA Test Current
R9
20 Ω range @ 1 mA Test Current
R10
200 Ω range @ 10 mA Test Current
R11
200 Ω range @ 1 mA Test Current
R12
200 Ω range @ 100 uA Test Current
R13
2 kΩ range @ 1 mA Test Current
R14
2 kΩ range @ 100 uA Test Current
R15
20 kΩ range @ 100 uA Test Current
R16
20 kΩ range @ 10 uA Test Current
R17
200 kΩ range @ 10 uA Test Current
R18
2 MΩ range @ 1 uA Test Current
R19
20 MΩ range @ 100 nA Test Current
Save Setup
Sn
Saves Current Setup to a specified location, where n=1-9
Set Trigger Type
T0
Fast Continuous on Talk or Front Panel Operation
T1
Fast One Shot on Talk or Front Panel Operation
T2
Delay Continuous on Talk or Front Panel Operation
[Default]
T3
Delay One Shot on Talk or Front Panel Operation
T4
Fast Continuous on GET
T5
Fast One Shot on GET
T6
Delay Continuous on GET
T7
Delay One Shot on GET
Status
U0
Send machine State
U1
Send Error Status
U2
Send Firmware Revision Level
U3
Send High Comparator Limit Value
U4
Send Low Comparator Limit Value
U5
Send Nominal Value
U6
Send High % Comparator Value
U7
Send Low % Comparator Value
Execute
X
Force Execution of preceding Command
Message Terminator
Y0
Append <CR><LF>EOI as terminators
Y1
Append <LF><CR>EOI as terminators
Y2
Append <CR>EOI as terminators
Y3
Append <LF>EOI as terminators
Table 5.6: GPIB Command Summary
