Maintenance
7–16
1502C MTDR Service Manual
2V
50nS
2V
100nS
Figure 7–10: Main Board TP1041 Main Board TP3040
2V
50nS
1V
10uS
Figure 7–11: Main Board TP3041 Main Board TP4040
(waveforms continued next page)
2V
20nS
100uS
2V
Figure 7–12: Main Board TP6010 Main Board TP7010
