Specifications
3–4
1502C MTDR Service Manual
Characteristic Performance Requirement Supplemental Information
Electromagnetic Compatibility
Radiated Susceptibility
VDE 0871 Class B
MIL-T-28800C
Emission per standard: EN50081–1
EN55022 Class B Radiated Emissions
EN55022 Class B Conducted Emissions
EN60555–2 AC Power Conducted Emissions
Immunity per standard EN50082–1
IEC 801–2 Electrostatic Discharge Immunity
IEC 801–3 RF Electromagnetic Field Immunity
IEC 801–4 Electrical Fast Transient/Burst Immunity,
Signal and I/O
IEC 801–5 Power Line Surge Immunity
MIL-STD-461A notice 4(EL), method MIL-STD-462 notice 3
for RS03 and RS03.1
CE02, CE04, CS02, CS06, RE02,
RE02.1
RS03, RS03.1 from 14 kHz to
10 GHz Limited to 1 V/m (greater
than 1 GHz, displayed noise charac-
teristics performance shall be:
"
10
m
r
peak or less, with 50
W
termina-
tion connected to RF input (16 aver-
ages)).
Physical Characteristics
Characteristic Description
Weight
without cover
with cover
with cover, chart recorder, and battery pack
14.25 lbs (6.46 kg)
15.75 lbs (7.14 kg)
19.75 lbs (8.96 kg)
Shipping Weight
domestic
export
25.5 lbs (11.57 kg)
25.5 lbs (11.57 kg)
Height 5.0 inches (127 mm)
Width
with handle
without handle
12.4 inches (315 mm)
11.8 inches (300 mm)
Depth
with cover on
with handle extended to front
16.5 inches (436 mm)
18.7 inches (490 mm)
