1502C MTDR Service Manual
A3A1 – POWER SUPPLY
✝
Back Side Components
CIRCUIT SCHEM LOCATION
NUMBER PAGE SCHEM BRD
TP1020 1A G2 B1
TP2010 1A B2 A2
TP2030 1A E6 C2
U1010 1A C4 A1
U1011 1A D3 A1
U1020A 1A B6 B1
U1020B 1A B6 B1
U1021A 1A B7 B1
U1021B 1A B8 B1
U1022 1A C6 B1
U1023 1A C7 B1
U1024B 1A E7 B1
U2010 1A G2 A2
U2030A 1A E8 C2
U2030B 1A F7 C2
U2030C 1A F7 C2
U2030D 1A F7 C2
U2030E 1A F7 C2
VR1012 1A D2 A1
